pIRES2-DsRed2 contains the internal ribosome entry site (IRES; 1, 2) of the encephalomyocarditis virus (ECMV) between the MCS and the Discosoma sp. red fluorescent protein (DsRed2; 3, 4) coding region. This permits both the gene of interest (cloned into the MCS) and the DsRed2 gene to be translated from a single bicistronic mRNA. pIRES2-DsRed2 is designed for the efficient selection (by flow cytometry or other methods) of transiently transfected mammalian cells expressing DsRed2 and the protein of interest. Thisvector can express DsRed2 alone at lower signal intensity. The vector can also be used to obtain stably transfected cell lines by drug and clonal selection. DsRed2 is a human codon-optimized (5) DsRed variant engineered for faster maturation and lower non-specific aggregation. The MCS in pIRES2-DsRed2 is located between the immediate early promoter of cytomegalovirus (PCMV IE) and the IRES sequence. SV40 polyadenylation signals downstream of the DsRed2 gene direct proper processing of the 3' end of the bicistronic mRNA.
The vector backbone also contains an SV40 origin for replication in mammalian cells expressing the SV40 T antigen. A neomycin-resistance cassette (Neor), consisting of the SV40 early promoter, the neomycin/kanamycin resistance gene of Tn5, and polyadenylation signals from the herpes simplex virus thymidine kinase (HSV TK) gene, allows stably transfected eukaryotic cells to be selected using G418. A bacterial promoter upstream of this cassette expresses kanamycin resistance in E. coli. The pIRES2-DsRed2 backbone also provides a pUC origin of replication for propagation in E. coli and an f1 origin for single-stranded DNA production.
pIRES2-DsRed2 can be used to quickly identify cells expressing a gene of interest by screening for DsRed2 fluorescence. Genes inserted into the MCS should include the initiating ATG codon. Selection of DsRed2-positive cells is possible 24 hr after transfection by flow cytometry or fluorescence microscopy. However, in some cases, up to 48 hr may be required for detection of red-emitting cells. pIRES2-DsRed2 and its derivatives can be introduced into mammalian cells using any standard transfection method. If required, stable transformants can be selected using G418 (6).
Propagation in E. coli
• Suitable host strains: DH5α, HB101, and other general purpose strains. Single-stranded DNA production requires
a host containing an F plasmid such as JM101 or XL1-Blue.
• Selectable marker: plasmid confers resistance to kanamycin (50 μg/ml) in E. coli hosts.
• E. coli replication origin: pUC
• Copy number: ~500
• Plasmid incompatibility group: pMB1/ColE1
LOCUS pIRES2-DsRed2 5264 bp DNA SYN
DEFINITION pIRES2-DsRed2
ACCESSION
KEYWORDS
SOURCE
ORGANISM other sequences; artificial sequences; vectors.
FEATURES Location/Qualifiers
source 1..5264
/organism="pIRES2-DsRed2"
/mol_type="other DNA"
promoter 10..562
/label="CMV_immearly_promoter"
misc_feature 65..352
/label="CAG_enhancer"
misc_feature 519..539
/label="CMV_fwd_primer"
promoter 520..589
/label="CMV_promoter"
misc_feature 666..1250
/label="IRES"
CDS complement(1155..1961)
/label="ORF frame 1"
/translation="MADYDLESRPLQEQVVAALGALVLLHDGVVLVVGGDVQLGVHVV
VAGQLHGLLGHVDRLELHQVVAAVLQLQGLVGLALQHAVAGVQALGGGLPAHGLLLHH
GAVGGEVHADELHLVDEAAVLQGGVLGHGRHAAVLEVHHALPLEALGEGQLLVVGDVG
GVLHVHLGAVLELGGQDVPGEGQGAALGHLQLHGVVALVGAALALALDLELVAVHGAL
HAHLEAHELGDDVLGGGHGCGHIIIVFFKGKPRPRGSGGLDVFLTSTKHM*"
CDS 1242..1931
/label="ORF frame 3"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
gene 1257..1928
/label="DsRed2"
/gene="DsRed2"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
misc_feature complement(1434..1454)
/label="dsRed1_N_primer"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
misc_feature 1846..1869
/label="dsRed1_C_primer"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
misc_feature 2143..2162
/label="EBV_rev_primer"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
rep_origin complement(2312..2618)
/label="f1_origin"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
promoter 2697..2725
/label="AmpR_promoter"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
misc_feature complement(2791..2811)
/label="pBABE_3_primer"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
misc_feature complement(2797..3012)
/label="SV40_enhancer"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
promoter 2809..3077
/label="SV40_promoter"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
rep_origin 2976..3053
/label="SV40_origin"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
misc_feature 3038..3057
/label="SV40pro_F_primer"
/translation="MATTMASSENVITEFMRFKVRMEGTVNGHEFEIEGEGEGRPYEG
HNTVKLKVTKGGPLPFAWDILSPQFQYGSKVYVKHPADIPDYKKLSFPEGFKWERVMN
FEDGGVATVTQDSSLQDGCFIYKVKFIGVNFPSDGPVMQKKTMGWEASTERLYPRDGV
LKGETHKALKLKDGGHYLVEFKSIYMAKKPVQLPGYYYVDAKLDITSHNEDYTIVEQY
ERTEGRHHLFL*"
CDS 3160..3954
/label="ORF frame 1"
/translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGR
PVLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDL
LSSHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDE
EHQGLAPAELFARLKASMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRY
QDIALATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF*"
gene 3163..3951
/label="NeoR/KanR"
/gene="NeoR/KanR"
/translation="MIEQDGLHAGSPAAWVERLFGYDWAQQTIGCSDAAVFRLSAQGR
PVLFVKTDLSGALNELQDEAARLSWLATTGVPCAAVLDVVTEAGRDWLLLGEVPGQDL
LSSHLAPAEKVSIMADAMRRLHTLDPATCPFDHQAKHRIERARTRMEAGLVDQDDLDE
EHQGLAPAELFARLKASMPDGEDLVVTHGDACLPNIMVENGRFSGFIDCGRLGVADRY
QDIALATRDIAEELGGEWADRFLVLYGIAAPDSQRIAFYRLLDEFF*"
CDS complement(3469..4005)
/label="ORF frame 3"
/translation="MAGWASLGRSFRTPESRSEELVKKAIEGDALRIGSGDTVKHEEA
VSPFAAKLFSNITGSQRYVLIAVRHTQPATVDESRKAAIFHHDIRQAGIAMGHDEILA
VGHARLEPGEQFGWREPLMLFVQIILIDKTGFHPSTCSLDAMFRLVVEWAGSRIKRMQ
PPHCISHDGYFLGRSKVR*"
terminator 4129..4398
/label="TK_PA_terminator"
/translation="MAGWASLGRSFRTPESRSEELVKKAIEGDALRIGSGDTVKHEEA
VSPFAAKLFSNITGSQRYVLIAVRHTQPATVDESRKAAIFHHDIRQAGIAMGHDEILA
VGHARLEPGEQFGWREPLMLFVQIILIDKTGFHPSTCSLDAMFRLVVEWAGSRIKRMQ
PPHCISHDGYFLGRSKVR*"
rep_origin 4546..5165
/label="pBR322_origin"
/translation="MAGWASLGRSFRTPESRSEELVKKAIEGDALRIGSGDTVKHEEA
VSPFAAKLFSNITGSQRYVLIAVRHTQPATVDESRKAAIFHHDIRQAGIAMGHDEILA
VGHARLEPGEQFGWREPLMLFVQIILIDKTGFHPSTCSLDAMFRLVVEWAGSRIKRMQ
PPHCISHDGYFLGRSKVR*"
ORIGIN
1 TAGTTATTAA TAGTAATCAA TTACGGGGTC ATTAGTTCAT AGCCCATATA TGGAGTTCCG
61 CGTTACATAA CTTACGGTAA ATGGCCCGCC TGGCTGACCG CCCAACGACC CCCGCCCATT
121 GACGTCAATA ATGACGTATG TTCCCATAGT AACGCCAATA GGGACTTTCC ATTGACGTCA
181 ATGGGTGGAG TATTTACGGT AAACTGCCCA CTTGGCAGTA CATCAAGTGT ATCATATGCC
241 AAGTACGCCC CCTATTGACG TCAATGACGG TAAATGGCCC GCCTGGCATT ATGCCCAGTA
301 CATGACCTTA TGGGACTTTC CTACTTGGCA GTACATCTAC GTATTAGTCA TCGCTATTAC
361 CATGGTGATG CGGTTTTGGC AGTACATCAA TGGGCGTGGA TAGCGGTTTG ACTCACGGGG
421 ATTTCCAAGT CTCCACCCCA TTGACGTCAA TGGGAGTTTG TTTTGGCACC AAAATCAACG
481 GGACTTTCCA AAATGTCGTA ACAACTCCGC CCCATTGACG CAAATGGGCG GTAGGCGTGT
541 ACGGTGGGAG GTCTATATAA GCAGAGCTGG TTTAGTGAAC CGTCAGATCC GCTAGCGCTA
601 CCGGACTCAG ATCTCGAGCT CAAGCTTCGA ATTCTGCAGT CGACGGTACC GCGGGCCCGG
661 GATCCGCCCC TCTCCCTCCC CCCCCCCTAA CGTTACTGGC CGAAGCCGCT TGGAATAAGG
721 CCGGTGTGCG TTTGTCTATA TGTTATTTTC CACCATATTG CCGTCTTTTG GCAATGTGAG
781 GGCCCGGAAA CCTGGCCCTG TCTTCTTGAC GAGCATTCCT AGGGGTCTTT CCCCTCTCGC
841 CAAAGGAATG CAAGGTCTGT TGAATGTCGT GAAGGAAGCA GTTCCTCTGG AAGCTTCTTG
901 AAGACAAACA ACGTCTGTAG CGACCCTTTG CAGGCAGCGG AACCCCCCAC CTGGCGACAG
961 GTGCCTCTGC GGCCAAAAGC CACGTGTATA AGATACACCT GCAAAGGCGG CACAACCCCA
1021 GTGCCACGTT GTGAGTTGGA TAGTTGTGGA AAGAGTCAAA TGGCTCTCCT CAAGCGTATT
1081 CAACAAGGGG CTGAAGGATG CCCAGAAGGT ACCCCATTGT ATGGGATCTG ATCTGGGGCC
1141 TCGGTGCACA TGCTTTACAT GTGTTTAGTC GAGGTTAAAA AAACGTCTAG GCCCCCCGAA
1201 CCACGGGGAC GTGGTTTTCC TTTGAAAAAC ACGATGATAA TATGGCCACA ACCATGGCCT
1261 CCTCCGAGAA CGTCATCACC GAGTTCATGC GCTTCAAGGT GCGCATGGAG GGCACCGTGA
1321 ACGGCCACGA GTTCGAGATC GAGGGCGAGG GCGAGGGCCG CCCCTACGAG GGCCACAACA
1381 CCGTGAAGCT GAAGGTGACC AAGGGCGGCC CCCTGCCCTT CGCCTGGGAC ATCCTGTCCC
1441 CCCAGTTCCA GTACGGCTCC AAGGTGTACG TGAAGCACCC CGCCGACATC CCCGACTACA
1501 AGAAGCTGTC CTTCCCCGAG GGCTTCAAGT GGGAGCGCGT GATGAACTTC GAGGACGGCG
1561 GCGTGGCGAC CGTGACCCAG GACTCCTCCC TGCAGGACGG CTGCTTCATC TACAAGGTGA
1621 AGTTCATCGG CGTGAACTTC CCCTCCGACG GCCCCGTGAT GCAGAAGAAG ACCATGGGCT
1681 GGGAGGCCTC CACCGAGCGC CTGTACCCCC GCGACGGCGT GCTGAAGGGC GAGACCCACA
1741 AGGCCCTGAA GCTGAAGGAC GGCGGCCACT ACCTGGTGGA GTTCAAGTCT ATCTACATGG
1801 CCAAGAAGCC CGTGCAGCTG CCCGGCTACT ACTACGTGGA CGCCAAGCTG GACATCACCT
1861 CCCACAACGA GGACTACACC ATCGTGGAGC AGTACGAGCG CACCGAGGGC CGCCACCACC
1921 TGTTCCTGTA GCGGCCGCGA CTCTAGATCA TAATCAGCCA TACCACATTT GTAGAGGTTT
1981 TACTTGCTTT AAAAAACCTC CCACACCTCC CCCTGAACCT GAAACATAAA ATGAATGCAA
2041 TTGTTGTTGT TAACTTGTTT ATTGCAGCTT ATAATGGTTA CAAATAAAGC AATAGCATCA
2101 CAAATTTCAC AAATAAAGCA TTTTTTTCAC TGCATTCTAG TTGTGGTTTG TCCAAACTCA
2161 TCAATGTATC TTAAGGCGTA AATTGTAAGC GTTAATATTT TGTTAAAATT CGCGTTAAAT
2221 TTTTGTTAAA TCAGCTCATT TTTTAACCAA TAGGCCGAAA TCGGCAAAAT CCCTTATAAA
2281 TCAAAAGAAT AGACCGAGAT AGGGTTGAGT GTTGTTCCAG TTTGGAACAA GAGTCCACTA
2341 TTAAAGAACG TGGACTCCAA CGTCAAAGGG CGAAAAACCG TCTATCAGGG CGATGGCCCA
2401 CTACGTGAAC CATCACCCTA ATCAAGTTTT TTGGGGTCGA GGTGCCGTAA AGCACTAAAT
2461 CGGAACCCTA AAGGGAGCCC CCGATTTAGA GCTTGACGGG GAAAGCCGGC GAACGTGGCG
2521 AGAAAGGAAG GGAAGAAAGC GAAAGGAGCG GGCGCTAGGG CGCTGGCAAG TGTAGCGGTC
2581 ACGCTGCGCG TAACCACCAC ACCCGCCGCG CTTAATGCGC CGCTACAGGG CGCGTCAGGT
2641 GGCACTTTTC GGGGAAATGT GCGCGGAACC CCTATTTGTT TATTTTTCTA AATACATTCA
2701 AATATGTATC CGCTCATGAG ACAATAACCC TGATAAATGC TTCAATAATA TTGAAAAAGG
2761 AAGAGTCCTG AGGCGGAAAG AACCAGCTGT GGAATGTGTG TCAGTTAGGG TGTGGAAAGT
2821 CCCCAGGCTC CCCAGCAGGC AGAAGTATGC AAAGCATGCA TCTCAATTAG TCAGCAACCA
2881 GGTGTGGAAA GTCCCCAGGC TCCCCAGCAG GCAGAAGTAT GCAAAGCATG CATCTCAATT
2941 AGTCAGCAAC CATAGTCCCG CCCCTAACTC CGCCCATCCC GCCCCTAACT CCGCCCAGTT
3001 CCGCCCATTC TCCGCCCCAT GGCTGACTAA TTTTTTTTAT TTATGCAGAG GCCGAGGCCG
3061 CCTCGGCCTC TGAGCTATTC CAGAAGTAGT GAGGAGGCTT TTTTGGAGGC CTAGGCTTTT
3121 GCAAAGATCG ATCAAGAGAC AGGATGAGGA TCGTTTCGCA TGATTGAACA AGATGGATTG
3181 CACGCAGGTT CTCCGGCCGC TTGGGTGGAG AGGCTATTCG GCTATGACTG GGCACAACAG
3241 ACAATCGGCT GCTCTGATGC CGCCGTGTTC CGGCTGTCAG CGCAGGGGCG CCCGGTTCTT
3301 TTTGTCAAGA CCGACCTGTC CGGTGCCCTG AATGAACTGC AAGACGAGGC AGCGCGGCTA
3361 TCGTGGCTGG CCACGACGGG CGTTCCTTGC GCAGCTGTGC TCGACGTTGT CACTGAAGCG
3421 GGAAGGGACT GGCTGCTATT GGGCGAAGTG CCGGGGCAGG ATCTCCTGTC ATCTCACCTT
3481 GCTCCTGCCG AGAAAGTATC CATCATGGCT GATGCAATGC GGCGGCTGCA TACGCTTGAT
3541 CCGGCTACCT GCCCATTCGA CCACCAAGCG AAACATCGCA TCGAGCGAGC ACGTACTCGG
3601 ATGGAAGCCG GTCTTGTCGA TCAGGATGAT CTGGACGAAG AGCATCAGGG GCTCGCGCCA
3661 GCCGAACTGT TCGCCAGGCT CAAGGCGAGC ATGCCCGACG GCGAGGATCT CGTCGTGACC
3721 CATGGCGATG CCTGCTTGCC GAATATCATG GTGGAAAATG GCCGCTTTTC TGGATTCATC
3781 GACTGTGGCC GGCTGGGTGT GGCGGACCGC TATCAGGACA TAGCGTTGGC TACCCGTGAT
3841 ATTGCTGAAG AGCTTGGCGG CGAATGGGCT GACCGCTTCC TCGTGCTTTA CGGTATCGCC
3901 GCTCCCGATT CGCAGCGCAT CGCCTTCTAT CGCCTTCTTG ACGAGTTCTT CTGAGCGGGA
3961 CTCTGGGGTT CGAAATGACC GACCAAGCGA CGCCCAACCT GCCATCACGA GATTTCGATT
4021 CCACCGCCGC CTTCTATGAA AGGTTGGGCT TCGGAATCGT TTTCCGGGAC GCCGGCTGGA
4081 TGATCCTCCA GCGCGGGGAT CTCATGCTGG AGTTCTTCGC CCACCCTAGG GGGAGGCTAA
4141 CTGAAACACG GAAGGAGACA ATACCGGAAG GAACCCGCGC TATGACGGCA ATAAAAAGAC
4201 AGAATAAAAC GCACGGTGTT GGGTCGTTTG TTCATAAACG CGGGGTTCGG TCCCAGGGCT
4261 GGCACTCTGT CGATACCCCA CCGAGACCCC ATTGGGGCCA ATACGCCCGC GTTTCTTCCT
4321 TTTCCCCACC CCACCCCCCA AGTTCGGGTG AAGGCCCAGG GCTCGCAGCC AACGTCGGGG
4381 CGGCAGGCCC TGCCATAGCC TCAGGTTACT CATATATACT TTAGATTGAT TTAAAACTTC
4441 ATTTTTAATT TAAAAGGATC TAGGTGAAGA TCCTTTTTGA TAATCTCATG ACCAAAATCC
4501 CTTAACGTGA GTTTTCGTTC CACTGAGCGT CAGACCCCGT AGAAAAGATC AAAGGATCTT
4561 CTTGAGATCC TTTTTTTCTG CGCGTAATCT GCTGCTTGCA AACAAAAAAA CCACCGCTAC
4621 CAGCGGTGGT TTGTTTGCCG GATCAAGAGC TACCAACTCT TTTTCCGAAG GTAACTGGCT
4681 TCAGCAGAGC GCAGATACCA AATACTGTCC TTCTAGTGTA GCCGTAGTTA GGCCACCACT
4741 TCAAGAACTC TGTAGCACCG CCTACATACC TCGCTCTGCT AATCCTGTTA CCAGTGGCTG
4801 CTGCCAGTGG CGATAAGTCG TGTCTTACCG GGTTGGACTC AAGACGATAG TTACCGGATA
4861 AGGCGCAGCG GTCGGGCTGA ACGGGGGGTT CGTGCACACA GCCCAGCTTG GAGCGAACGA
4921 CCTACACCGA ACTGAGATAC CTACAGCGTG AGCTATGAGA AAGCGCCACG CTTCCCGAAG
4981 GGAGAAAGGC GGACAGGTAT CCGGTAAGCG GCAGGGTCGG AACAGGAGAG CGCACGAGGG
5041 AGCTTCCAGG GGGAAACGCC TGGTATCTTT ATAGTCCTGT CGGGTTTCGC CACCTCTGAC
5101 TTGAGCGTCG ATTTTTGTGA TGCTCGTCAG GGGGGCGGAG CCTATGGAAA AACGCCAGCA
5161 ACGCGGCCTT TTTACGGTTC CTGGCCTTTT GCTGGCCTTT TGCTCACATG TTCTTTCCTG
5221 CGTTATCCCC TGATTCTGTG GATAACCGTA TTACCGCCAT GCAT
//
