pEX-1

LOCUS       pEX-1                   4505 bp DNA     circular SYN 12-NOV-2024
SOURCE      synthetic DNA construct
  ORGANISM  synthetic DNA construct
REFERENCE   1  (bases 1 to 4505)
  AUTHORS   Ming
  TITLE     Direct Submission
  JOURNAL   Exported Nov 12, 2024 from SnapGene 6.0.2 to Vector NTI(R) format
            https://www.biofeng.com
COMMENT     VNTDATE|1073779200|
COMMENT     VNTDBDATE|1073779200|
COMMENT     VNTNAME|pEX-1|
COMMENT     VNTAUTHORNAME|Ming|
FEATURES             Location/Qualifiers
     primer_bind     166..182
                     /label=M13 fwd
                     /note="common sequencing primer, one of multiple similar
                     variants"
     promoter        218..236
                     /label=T7 promoter
                     /note="promoter for bacteriophage T7 RNA polymerase"
     protein_bind    237..261
                     /label=lac operator
                     /bound_moiety="lac repressor encoded by lacI"
                     /note="The lac repressor binds to the lac operator to
                     inhibit transcription in E. coli. This inhibition can be
                     relieved by adding lactose or
                     isopropyl-beta-D-thiogalactopyranoside (IPTG)."
     RBS             265..287
                     /label=RBS
                     /note="efficient ribosome binding site from bacteriophage
                     T7 gene 10 (Olins and Rangwala, 1989)"
     terminator      421..467
                     /label=T7 terminator
                     /note="transcription terminator for bacteriophage T7 RNA
                     polymerase"
     promoter        713..790
                     /gene="lacI"
                     /label=lacI promoter
     CDS             791..1873
                     /codon_start=1
                     /gene="lacI"
                     /product="lac repressor"
                     /label=lacI
                     /note="The lac repressor binds to the lac operator to
                     inhibit transcription in E. coli. This inhibition can be
                     relieved by adding lactose or
                     isopropyl-beta-D-thiogalactopyranoside (IPTG)."
                     /translation="MKPVTLYDVAEYAGVSYQTVSRVVNQASHVSAKTREKVEAAMAEL
                     NYIPNRVAQQLAGKQSLLIGVATSSLALHAPSQIVAAIKSRADQLGASVVVSMVERSGV
                     EACKAAVHNLLAQRVSGLIINYPLDDQDAIAVEAACTNVPALFLDVSDQTPINSIIFSH
                     EDGTRLGVEHLVALGHQQIALLAGPLSSVSARLRLAGWHKYLTRNQIQPIAEREGDWSA
                     MSGFQQTMQMLNEGIVPTAMLVANDQMALGAMRAITESGLRVGADISVVGYDDTEDSSC
                     YIPPLTTIKQDFRLLGQTSVDRLLQLSQGQAVKGNQLLPVSLVKRKTTLAPNTQTASPR
                     ALADSLMQLARQVSRLESGQ"
     promoter        1922..1952
                     /label=lac promoter
                     /note="promoter for the E. coli lac operon"
     protein_bind    1960..1976
                     /label=lac operator
                     /bound_moiety="lac repressor encoded by lacI"
                     /note="The lac repressor binds to the lac operator to
                     inhibit transcription in E. coli. This inhibition can be
                     relieved by adding lactose or
                     isopropyl-beta-D-thiogalactopyranoside (IPTG)."
     primer_bind     1984..2000
                     /label=M13 rev
                     /note="common sequencing primer, one of multiple similar
                     variants"
     primer_bind     complement(2016..2032)
                     /label=M13 fwd
                     /note="common sequencing primer, one of multiple similar
                     variants"
     rep_origin      complement(2324..2912)
                     /direction=LEFT
                     /label=ori
                     /note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
                     replication"
     CDS             complement(3083..3943)
                     /codon_start=1
                     /gene="bla"
                     /product="beta-lactamase"
                     /label=AmpR
                     /note="confers resistance to ampicillin, carbenicillin, and
                     related antibiotics"
     promoter        complement(3944..4048)
                     /gene="bla"
                     /label=AmpR promoter
     rep_origin      4075..4503
                     /direction=RIGHT
                     /label=f1 ori
                     /note="f1 bacteriophage origin of replication; arrow
                     indicates direction of (+) strand synthesis"
ORIGIN
        1 aacaaaatat taacgcttac aatttccatt cgccattcag gctgcgcaac tgttgggaag
       61 ggcgatcggt gcgggcctct tcgctattac gccagctggc gaaaggggga tgtgctgcaa
      121 ggcgattaag ttgggtaacg ccagggtttt cccagtcacg acgttgtaaa acgacggcca
      181 gtgccgaatt ctgctggact ttccaaaatg tcgagcttaa tacgactcac tataggggaa
      241 ttgtgagcgg ataacaattc cccttttgtt taactttaag aaggagatat cgatcgctct
      301 cctcggcgcg ccagatctca agcttaacta gctagcggac cgacgcgtta aacgcggccg
      361 ctcgaggttt aaacggccgg ccacatgact gactgagcca cgataaccgc tgagcaataa
      421 ctagcataac cccttggggc ctctaaacgg gtcttgaggg gttttttccc accagccttg
      481 tcctaatccg cggcggttcc tggccttttg ctggcctttt gctcacatgt tctttcctgc
      541 gttatcccct gattctgtgg ataaccgtat taccgccttt gagtgagctg ataccgctcg
      601 ccgcagccga acgaccgagc gcagcgagtc agtgagcgag gaagcggaag agcgcctgat
      661 gcggtatttt ctccttacgc atctgtgcgg tatttcacac cgcataaatt ccgacaccat
      721 cgaatggcgc aaaacctttc gcggtatggc atgatagcgc ccggaagaga gtcaattcag
      781 ggtggtgaat gtgaaaccag taacgttata cgatgtcgca gagtatgccg gtgtctctta
      841 tcagaccgtt tcccgcgtgg tgaaccaggc cagccacgtt tctgcgaaaa cgcgggaaaa
      901 agtggaagcg gcgatggcgg agctgaatta cattcccaac cgcgtggcac aacaactggc
      961 gggcaaacag tcgttgctga ttggcgttgc cacctccagt ctggccctgc acgcgccgtc
     1021 gcaaattgtc gcggcgatta aatctcgcgc cgatcaactg ggtgccagcg tggtggtgtc
     1081 gatggtagaa cgaagcggcg tcgaagcctg taaagcggcg gtgcacaatc ttctcgcgca
     1141 acgagtcagt gggctgatca ttaactatcc gctggatgac caggatgcca ttgctgtgga
     1201 agctgcctgc actaatgttc cggcgttatt tcttgatgtc tctgaccaga cacccatcaa
     1261 cagtattatt ttctcccatg aagacggtac gcgactgggc gtggagcatc tggtcgcatt
     1321 gggtcaccag caaatcgcgc tgttagcggg cccattaagt tctgtctcgg cgcgtctgcg
     1381 tctggctggc tggcataaat atctcactcg caatcaaatt cagccgatag cggaacggga
     1441 aggcgactgg agtgccatgt ccggttttca acaaaccatg caaatgctga atgagggcat
     1501 cgttcccact gcgatgctgg ttgccaacga tcagatggcg ctgggcgcaa tgcgcgccat
     1561 taccgagtcc gggctgcgcg ttggtgcgga tatctcggta gtgggatacg acgataccga
     1621 agacagctca tgttatatcc cgccgttaac caccatcaaa caggattttc gcctgctggg
     1681 gcaaaccagc gtggaccgct tgctgcaact ctctcagggc caggcggtga agggcaatca
     1741 gctgttgccc gtctcactgg tgaaaagaaa aaccaccctg gcgcccaata cgcaaaccgc
     1801 ctctccccgc gcgttggccg attcattaat gcagctggca cgacaggttt cccgactgga
     1861 aagcgggcag tgagcgcaac gcaattaatg taagttagct cactcattag gcaccccagg
     1921 ctttacactt tatgcttccg gctcgtatgt tgtgtggaat tgtgagcgga taacaatttc
     1981 acacaggaaa cagctatgac catgattacg gattcactgg ccgtcgtttt acaacgtcgt
     2041 gactgggaaa accctggcgt tacccaactt aatcgccttg cagcacatcc ccctttcgcc
     2101 agctggcgta atagcgaaga ggcccgcacc gatggatccg ctcttccgct tcctcgctca
     2161 ctgactcgct gcgctcggtc gttcggctgc ggcgagcggt atcagctcac tcaaaggcgg
     2221 taatacggtt atccacagaa tcaggggata acgcaggaaa gaacatgtga gcaaaaggcc
     2281 agcaaaaggc caggaaccgt aaaaaggccg cgttgctggc gtttttccat aggctccgcc
     2341 cccctgacga gcatcacaaa aatcgacgct caagtcagag gtggcgaaac ccgacaggac
     2401 tataaagata ccaggcgttt ccccctggaa gctccctcgt gcgctctcct gttccgaccc
     2461 tgccgcttac cggatacctg tccgcctttc tcccttcggg aagcgtggcg ctttctcata
     2521 gctcacgctg taggtatctc agttcggtgt aggtcgttcg ctccaagctg ggctgtgtgc
     2581 acgaaccccc cgttcagccc gaccgctgcg ccttatccgg taactatcgt cttgagtcca
     2641 acccggtaag acacgactta tcgccactgg cagcagccac tggtaacagg attagcagag
     2701 cgaggtatgt aggcggtgct acagagttct tgaagtggtg gcctaactac ggctacacta
     2761 gaagaacagt atttggtatc tgcgctctgc tgaagccagt taccttcgga aaaagagttg
     2821 gtagctcttg atccggcaaa caaaccaccg ctggtagcgg tggttttttt gtttgcaagc
     2881 agcagattac gcgcagaaaa aaaggatctc aagaagatcc tttgatcttt tctacggggt
     2941 ctgacgctca gtggaacgaa aactcacgtt aagggatttt ggtcatgaga ttatcaaaaa
     3001 ggatcttcac ctagatcctt ttaaattaaa aatgaagttt taaatcaatc taaagtatat
     3061 atgagtaaac ttggtctgac agttaccaat gcttaatcag tgaggcacct atctcagcga
     3121 tctgtctatt tcgttcatcc atagttgcct gactccccgt cgtgtagata actacgatac
     3181 gggagggctt accatctggc cccagtgctg caatgatacc gcgagaccca cgctcaccgg
     3241 ctccagattt atcagcaata aaccagccag ccggaagggc cgagcgcaga agtggtcctg
     3301 caactttatc cgcctccatc cagtctatta attgttgccg ggaagctaga gtaagtagtt
     3361 cgccagttaa tagtttgcgc aacgttgttg ccattgctac aggcatcgtg gtgtcacgct
     3421 cgtcgtttgg tatggcttca ttcagctccg gttcccaacg atcaaggcga gttacatgat
     3481 cccccatgtt gtgcaaaaaa gcggttagct ccttcggtcc tccgatcgtt gtcagaagta
     3541 agttggccgc agtgttatca ctcatggtta tggcagcact gcataattct cttactgtca
     3601 tgccatccgt aagatgcttt tctgtgactg gtgagtactc aaccaagtca ttctgagaat
     3661 agtgtatgcg gcgaccgagt tgctcttgcc cggcgtcaat acgggataat accgcgccac
     3721 atagcagaac tttaaaagtg ctcatcattg gaaaacgttc ttcggggcga aaactctcaa
     3781 ggatcttacc gctgttgaga tccagttcga tgtaacccac tcgtgcaccc aactgatctt
     3841 cagcatcttt tactttcacc agcgtttctg ggtgagcaaa aacaggaagg caaaatgccg
     3901 caaaaaaggg aataagggcg acacggaaat gttgaatact catactcttc ctttttcaat
     3961 attattgaag catttatcag ggttattgtc tcatgagcgg atacatattt gaatgtattt
     4021 agaaaaataa acaaataggg gttccgcgca catttccccg aaaagtgcca cctgacgcgc
     4081 cctgtagcgg cgcattaagc gcggcgggtg tggtggttac gcgcagcgtg accgctacac
     4141 ttgccagcgc cctagcgccc gctcctttcg ctttcttccc ttcctttctc gccacgttcg
     4201 ccggctttcc ccgtcaagct ctaaatcggg ggctcccttt agggttccga tttagtgctt
     4261 tacggcacct cgaccccaaa aaacttgatt agggtgatgg ttcacgtagt gggccatcgc
     4321 cctgatagac ggtttttcgc cctttgacgt tggagtccac gttctttaat agtggactct
     4381 tgttccaaac tggaacaaca ctcaacccta tctcggtcta ttcttttgat ttataaggga
     4441 ttttgccgat ttcggcctat tggttaaaaa atgagctgat ttaacaaaaa tttaacgcga
     4501 atttt
//
